Indoor systems
Indoor systems
Indoor Radiant Electrical Floor Heating System
Switched On Radiant indoor systems could be installed under most surfaces including Tile, Hardwood, Laminated Timber, Luxury Vinyl, and Carpets.
Radiant electrical floor heating creates maximum thermal spread which results in all-around floor surface and ambient comfort.
The systems are cost effective to operate resulting in optimum energy efficiency.
Easy installation for years of hassle-free comfort.
At Switched-On Radiant we have a system for your specific requirements:
Cable with Membrane
- These elements are supplied at constant wattage and length with various sizes available for specific room or area coverage.
- The element output is 15w per sq ft ensuring optimum thermal spread.
- The recommended element installation spacing is 3” / 3.75”
- The size and coverage will be determined by the requirement and the specific indoor space.
- It is not recommended to install the element under fixtures as that will complicate the repair process when required.
- Elements are available in both 120v / 240v.
- All Switched On Radiant materials are supplied as per manufacturer warranties.
- No third-party repair contractors are required for element or thermostat repairs as we manufacture our repair equipment in-house and our skilled engineers are trained to locate and repair any faulty system.
- Estimated running cost at 15.5 cents per KW per hour.
Cable with Fixing Strips
- These elements are supplied at constant wattage and length with various sizes available for specific area coverage.
- The element output is 15w per sq ft ensuring optimum thermal spread.
- The recommended element installation spacing is 3” / 3.75”
- The size and coverage will be determined by the requirement and the specific indoor space.
- It is not recommended to install the element under fixtures as that will complicate the repair process when required.
- Elements are available in both 120v / 240v.
- All Switched On Radiant materials are supplied as per manufacturer warranties.
- No third-party repair contractors are required for element or thermostat repairs as we manufacture our repair equipment in-house and our skilled engineers are trained to locate and repair any faulty system.
- Estimated running cost at 15.5 cents per KW per hour.
Advantages of using the different systems:
Cable & Strip
- The cable and strip method will be cheaper compared to the Cable with Membrane
- The cable and strip require the subfloor to be in good condition.
Cable & Membrane
- The best option for the subfloor which is not in good condition.
- Installation is faster compared to cable with the strip method.
- The membrane creates a waterproof barrier.
Roll–Cut and Turn System:
- These elements are supplied at constant wattage and length with various sizes available for specific room or area coverage.
- The recommended element installation spacing is 3” / 3.75”
- The size and coverage will be determined by the requirement and the specific indoor space.
- It is not recommended to install the element under fixtures as that will complicate the repair process when required.
- Elements are available in both 120v / 240v.
- All Switched On Radiant materials are supplied as per manufacturer warranties.
- No third-party repair contractors are required for element or thermostat repairs as we manufacture our repair equipment in-house and our skilled engineers are trained to locate and repair any faulty system.
- Estimated running cost at 15.5 cents per KW per hour.
Carpet and Floating Timber / Laminated Systems
- These elements are embedded in a foil layer and are supplied at constant wattage and length.
- The element output is 15w per sq ft ensuring optimum thermal spread.
- The element set spacing in the foil material is 3”
The size and coverage will be determined by the requirement and the specific indoor space. - It is not recommended to install the element under fixtures as that will complicate the repair process when required.
- Elements are available in both 120v / 240v.
- All Switched On Radiant materials are supplied as per manufacturer warranties.
- No third-party repair contractors are required for element or thermostat repairs as we manufacture our repair equipment in-house and our skilled engineers are trained to locate and repair any faulty system.
- Estimated running cost at 15.5 cents per KW per hour.
Carpet Heating
Our system features a durable thin element that is installed directly on top of the carpet padding, underneath the carpet. Unlike conventional heating elements, our system distributes heat evenly throughout the floor surface, resulting in improved energy efficiency.
Additionally, our system operates silently, is odor-free, and does not dry out the air. It is controlled by a thermostat for hassle-free operation.
To ensure the utmost safety, we recommend the installation of a floor sensor to regulate the heating elements and prevent any potential damage to the floor surface covering.
Furthermore, our elements are manufactured using a foil-woven fiber material, making them waterproof and equipped with internal ground shield protection for added safety.
The product is constructed to be highly durable and can easily withstand heavy furniture loads on top.
Laminate Timber Heating
Unlike traditional heating elements, our radiant floor heating system distributes heat evenly across the entire floor surface, resulting in improved energy efficiency. Additionally, our system operates silently and is odor-free, without drying out the air. It is conveniently controlled by a thermostat, ensuring hassle-free operation.
To optimize heat retention and prevent downward heat loss, it is crucial to use high-quality underlayment. Our elements are designed to avoid overheating, and the installation of a floor sensor is vital to regulate the heating elements and protect the floor surface.
Please be sure to review the heat specifications provided by each floor surface supplier to ensure that the sensor limits are set within the required heat range for the specific floor surface product being installed.
The Laminate Timber Heating elements are manufactured using a waterproof foil-woven fiber material, which also includes internal ground shield protection. This ensures durability and resistance to heavy furniture loads.
Indoor Floor Insulation
Floor Underlayment 2.8 EPP Black
- 2.8# pcf density Expanded Polypropylene
- Closed cell material
- Benefits
- Noise damping
- Vibration damping
- Fatigue relief on all joints
- Moisture control
- Heat and cold-resistant, will not rot, support mold and mildew, or moisture
- 3mm, 5mm, 6mm, and 10mm thicknesses available. Additional thicknesses can be skived by request.
- Sheet size is 48×72 (utilize for best pad yield)
- Can be cut to size. 12″ x 12″, 24″ x 24″, 36 x 24′, 36″ x 26′
- ASTM C627 Robinson Floor Test Certified
Greater Energy Efficiency
The thicker the insulation below the floor heater, the greater the energy -efficiency. However, deeper insulation will affect floor build-up height. Warmup insulation products come in a range of depths and sizes to provide you with the optimal solution for your project to prevent energy wastage.
Suitable for all subfloors.
Our insulation products are suitable for use with all subfloors and can be used with all floor finishes.
Some floor heating systems require a specific combination of insulation and accessories for a successful heating solution.
For use in any project.
All our insulation products can be installed in new-build or renovation projects. For use in older properties with high levels of heat loss, a floor heater with insulation may not deliver the necessary heat output for optimal comfort.
Whilst insulation may seem like an additional expense when installing a floor heater insulation will improve the performance and energy efficiency.
Shower Floor, Bench, and Steam Room Systems
- Designs with drain cuts are available to ensure smooth installation.
- These elements are supplied at constant wattage and length with sizes available for a specific shower size.
- The element output is 15w per sq ft ensuring optimum thermal spread.
- The recommended element installation spacing is 3” for colder locations but could be adjusted in warmer climate areas depending on location.
- The element sizes/coverage is determined according to the specific space to be heated.
- Elements are available in 120v only for this specific application.
- All Switched On Radiant materials are supplied as per manufacturer warranties.
- No third-party repair contractors are required for element or thermostat repairs as we manufacture our repair equipment in-house and our skilled engineers are trained to locate and repair any faulty system.
- Estimated running cost at 15.5 cents per KW per hour.
Indoor Concrete Slab Systems
Installed under stained or polished concrete Cable and Mat Systems
- These elements are supplied at constant wattage and length with various sizes available for a specific room or area.
- The element output is 20w per sq ft ensuring optimum thermal spread.
- The recommended element installation spacing is 3” for colder locations but could be adjusted in warmer climate areas depending on location.
- The element size and coverage will be determined by the requirement and the specific indoor space.
- It is not recommended to install the element under bathtubs or cabinetry as this will result in having to remove these fixtures should any troubleshooting be required.
- Elements are available in both 120 / 240v.
- All Switched On Radiant elements are supplied and installed with a 10-year warranty – please see warranty information.
- Estimated running cost at 15.5 cents per KW per hour.
Tile / Hardwood Timber Heating Cable with Membrane
Please refer to Size and Output chart Below.
Cable with strip
Please refer to Size and Output chart Below.
Tile / Hardwood Timber Heating Mat
Please refer to Size and Output chart Below.
